KOMATSU PC490LC
Specifications & Parameters
| Engine Model | SAA6D125E-6A |
| Rated Power(kW) | 270 |
| Engine Revolutions(rpm) | 1900 |
| Maximum Torque(N·m) | 1280 |
| Inject Type | Direct Injection |
| Fuel consumption(L/h) | 13-16 |
| Engine Displacement(L) | 11.04 |
| Emisson | Stage IIIB |
| Track width(mm) | 800 |
| Fuel Tank(L) | 400 |
| Hydraulic Tank(L) | 210 |
| Travel Speed(km/h) | 5.5 |
| Bucket Capacity(m³) | 3.5 |
| Bucket Digging Force(kN) | 315 |
| Boom Length(mm) | 6700 |
| Stick Length(mm) | 3300 |
| Maximum Excavation Radius(mm) | 11360 |
| Maximum Digging Height(mm) | 7860 |
| Maximum Digging Depth(mm) | 6780 |
| Specifications(mm) | 11910×3690×3875 |
| Operating Weight(kg&ton) | 47910 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | Japan |
| Year of Production | 2018 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price. |
Features
Super Powerful Low-Maintenance Stage IIIB Mining Engine
Adopts SAA6D125E-6A six-cylinder turbocharged common rail engine, net power 268kW, displacement 11.04L, EU Stage IIIB emission standard. Only DPF passive regeneration without urea SCR system, fewer consumables and low long-term open-pit mining maintenance cost. Extra high low-end torque guarantees constant stable power for heavy rock digging and all-day hammer breaking without power stall.
Reinforced Extended LC Heavy-Duty Mining Undercarriage
8 track rollers with long ground contact length, wider LC gauge effectively reduces ground pressure. Total operating weight reaches 47.91t, over-side lifting capacity greatly improved vs 40-ton series excavators, outstanding anti-sinking performance on muddy open-pit ground, superior stability for deep digging and heavy ore loading. Full-length stone guard plates protect undercarriage from rock impact abrasion.
High-Flow HydrauMind Regenerative Hydraulics
Dual variable displacement main pumps deliver total flow up to 620L/min. Boom & stick energy regeneration stabilizes hydraulic pressure during round-the-clock hard rock breaking, smooth synchronized compound movements and ultra-precise fine control. Factory pre-installed bi-directional large-flow auxiliary hydraulic circuit directly fits 50t heavy hydraulic breakers, grapples and tilt quick couplers without refitting.
Versatile Large-Capacity Mining Working Equipment
Standard 3.5m³ heavy rock bucket greatly improves ore loading efficiency, perfectly suitable for large quarry, mass backfilling, river dredging and heavy foundation excavation multi-scenarios. Optional long deep-dig stick and short heavy hammer stick for customized mining jobs.
Mine-Oriented Safe Intelligent Operator Cab
ROPS/FOPS falling-object protection air-conditioned cab with standard front stone guard net, four-point shock absorption and heated air suspension seat. 10-inch touch monitor displays DPF regeneration status, real-time fuel consumption and load curve clearly. Standard KomVision 4-way panoramic camera + pedestrian collision warning system enhances safety in open pit quarries. New-generation KOMTRAX telematics supports full digital fleet remote monitoring, location tracking and maintenance reminder.
Convenient Ground-Level Daily Maintenance
All service access ports are arranged at ground level, single-person daily inspection of engine oil, filters and hydraulic oil without climbing equipment, effectively cutting costly mine downtime.
Interested in used KOMATSU PC490LC excavator? Click the WhatsApp icon to chat with our sales team for a quicker reply, or leave us a message through the contact form below. If you are looking for a different brand or model, please tell us your purchasing requirements, and we will do our best to help you find the right machine. Send Inquiry
