KOMATSU PC375LC-11M0
Specifications & Parameters
| Engine Model | SAA6D114E-6 |
| Rated Power(kW) | 202.3 |
| Engine Revolutions(rpm) | 1950 |
| Maximum Torque(N·m) | 1140 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 14-19 |
| Engine Displacement(L) | 8.85 |
| Emisson | Stage IV |
| Track width(mm) | 800 |
| Fuel Tank(L) | 600 |
| Hydraulic Tank(L) | 172 |
| Travel Speed(km/h) | 5.5 |
| Bucket Capacity(m³) | 2.1 |
| Bucket Digging Force(kN) | 246 |
| Boom Length(mm) | 6400 |
| Stick Length(mm) | 3300 |
| Maximum Excavation Radius(mm) | 11180 |
| Maximum Digging Height(mm) | 9995 |
| Maximum Digging Depth(mm) | 7145 |
| Specifications(mm) | 11120×3345×3400 |
| Operating Weight(kg&ton) | 36600 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | Japan |
| Year of Production | 2020 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
Features
Equipped with original Komatsu SAA6D114 six-cylinder China IV engine, 202.3kW rated power & 1140N·m massive low-speed torque, stable full power under high temperature & high altitude open-pit mines. Built-in swing energy recovery hybrid system cuts fuel consumption by around 15%, long aftertreatment regeneration interval reduces long-term mining maintenance cost.
36.6-ton extended 10-roller wide LC undercarriage with 800mm heavy-duty mining tracks balances ground pressure to avoid sinking on muddy riverbank ground. Full heat-treated heavy-duty track components extend service life by 20% in open-pit mining sites.
Standard 6.4m boom + 3.3m arm matched with 2.0m³ rock bucket delivers larger loading volume and stronger digging power than 33-ton machines. Optional short arm for rock breaking & long arm for deep dredging covers all quarry, mass loading and river dredging jobs.
Hybrid regenerative load-sensing hydraulic system with auto dig boost & heavy lift mode gets auxiliary power from swing motor, providing powerful breakout force for rock breaking and mass loading while greatly reducing fuel consumption.
Reinforced heavy mining boom & stick with fully annealed strengthened welds and enlarged pins/bushings resist rock impact and distortion, minimizing machine downtime during long-term quarry and demolition work.
Factory bi-directional high-flow auxiliary hydraulic lines dedicated for rock hammers support heavy breakers, grapples and quick couplers without extra pipe refitting, multi-purpose for mining, earthmoving and rock breaking tasks.
Komtrax remote telematics system enables real-time monitoring of fuel consumption, working hours and fault alerts via mobile devices for efficient large quarry fleet operation management.
All ground-level service access points eliminate climbing work for fluid & filter replacement, shortening maintenance downtime by 45%.
Interested in used KOMATSU PC375LC-11M0 excavator? Click the WhatsApp icon to chat with our sales team for a quicker reply, or leave us a message through the contact form below. If you are looking for a different brand or model, please tell us your purchasing requirements, and we will do our best to help you find the right machine. Send Inquiry
