Komatsu PC225LC-11M0
Specifications & Parameters
| Engine Model | SAA6D107E-3 |
| Rated Power(kW) | 123.2 |
| Engine Revolutions(rpm) | 2000 |
| Maximum Torque(N·m) | 710 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 10.5-14 |
| Engine Displacement(L) | 6.69 |
| Emisson | Stage IV |
| Track width(mm) | 600 |
| Fuel Tank(L) | 410 |
| Hydraulic Tank(L) | 155 |
| Travel Speed(km/h) | 5.1 |
| Bucket Capacity(m³) | 1.4 |
| Bucket Digging Force(kN) | 225 |
| Boom Length(mm) | 5900 |
| Stick Length(mm) | 2900 |
| Maximum Excavation Radius(mm) | 9875 |
| Maximum Digging Height(mm) | 10000 |
| Maximum Digging Depth(mm) | 6620 |
| Specifications(mm) | 10100×3290×3160 |
| Operating Weight(kg&ton) | 23600 |
| Size Class | Medium |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | Japan |
| Year of Production | 2023 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
Features
23‑ton class versatile mid‑size LC crawler excavator, widely deployed for urban construction, foundation excavation, site grading, aggregate handling, quarry secondary breaking and general earth‑moving projects.
Equipped with original Komatsu SAA6D107E‑3 six‑cylinder turbo after‑cooled diesel engine, rated power 123.2 kW, China‑IV emission standard. Multiple selectable working modes and auto‑idle‑stop function balance powerful output and fuel‑saving performance, delivers stable performance under high‑intensity dusty construction jobsites.
LC extended wide‑track undercarriage with 8 track rollers per side, thickened track links and wear‑resistant track shoes. Optimized ground‑pressure distribution improves stability during digging and truck‑loading cycles, prevents sinking on soft muddy ground and extends service life in abrasive working conditions.
Standard boom‑arm assembly matched with 1.2‑1.4 m³ general‑purpose bucket provides strong breakout force for hard‑soil digging and blasted rock material handling. Optional short breaking arm and long‑reach front adapt to rock breaking, deep trenching and river‑bank excavation assignments.
Advanced CLSS closed‑center load‑sensing hydraulic system with high‑flow main pump, max pump flow reaches 490 L/min. Six working‑mode selections and one‑touch power‑boost function shorten working cycle times, supports continuous operation of medium‑size hydraulic breakers, ensures smooth compound movements and precise fine‑control performance.
Thickened boom & stick assembly with full‑penetration reinforced welds and enlarged heavy‑duty pins & bushings. Robust structural design resists rock impact and abrasion, reduces oil‑leak risks and minimizes unplanned downtime for long‑term heavy‑duty operations.
Factory‑pre‑installed bi‑directional auxiliary hydraulic lines support hydraulic breakers, grapples and quick couplers without extra on‑site pipe modification. Multi‑attachment compatibility meets diversified tasks including earth‑moving, demolition and rock‑breaking works.
ROPS‑FOPS certified spacious operator cab with viscous vibration‑damping mounts, multi‑language color LCD monitor, rear‑view camera and USB port. Komtrax telematics enables real‑time remote monitoring of working hours, fuel consumption and fault codes for efficient jobsite fleet management.
Major daily‑maintenance service inspection points adopt ground‑level side‑access layout. Operators complete fluid replacement and filter maintenance without climbing upper structures, saving service time and improving overall jobsite efficiency.
Interested in used Komatsu PC225LC-11M0 excavator? Click the WhatsApp icon to chat with our sales team for a quicker reply, or leave us a message through the contact form below. If you are looking for a different brand or model, please tell us your purchasing requirements, and we will do our best to help you find the right machine. Send Inquiry
