Used DEVELON DX55W-7
Parameters
| Engine Model | Yanmar 4TNV98-E |
| Rated Power(kW) | 40.8 |
| Engine Revolutions(rpm) | 2400 |
| Maximum Torque(N·m) | 206 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 3-4 |
| Engine Displacement(L) | 3.319 |
| Emisson | Tier4 |
| Track width(mm) | 380 |
| Fuel Tank(L) | 120 |
| Hydraulic Tank(L) | 72 |
| Travel Speed(km/h) | 30 |
| Bucket Capacity(m³) | 0.175 |
| Bucket Digging Force(kN) | 43 |
| Boom Length(mm) | 3000 |
| Stick Length(mm) | 1600 |
| Maximum Excavation Radius(mm) | 6110 |
| Maximum Digging Height(mm) | 4260 |
| Maximum Digging Depth(mm) | 3495 |
| Specifications(mm) | 6120×1920×2680 |
| Operating Weight(kg&ton) | 5550 |
| Size Class | Mini |
| Power Type | Diesel |
| Walking Mode | Wheel |
| Country of Origin | China |
| Year of Production | 2021 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Check the latest price. |
Features
Original Yanmar 4-cylinder turbo diesel engine, Tier3 & Stage V dual emission options. DX55W-7M without AdBlue for low maintenance cost, tolerant to regular construction diesel and stable operation up to 4500m altitude; DX55W-7K complies with EU Stage V regulation with full global spare parts support.
124 L/min load-sensing regeneration hydraulic system with smooth combined movements, matched with 0.175m³ standard bucket, high efficiency for municipal trenching, road maintenance and pipeline construction projects.
Wheeled design with max travel speed up to 30 km/h, no flatbed truck required for short-distance site transfer to save transport cost. 900mm left-right boom swing enables flexible operation on narrow streets and sidewalks without large machine relocation.
Heavy-duty thickened HD boom & arm with heat-treated wear-resistant pins, strong anti-deformation performance under long-term digging and rock breaking. Hydraulic oscillating front axle ensures smooth driving on uneven paved roads.
Standard 1920mm wide dozer blade for ground leveling and machine stabilization; optional hydraulic outriggers greatly improve lifting stability during pipe and material handling.
Ground-level centralized filter layout for convenient daily maintenance, low long-term service cost and high residual value in global wheeled mini excavator market.
Multiple attachments optional: hydraulic quick coupler, rock breaker, log grapple, wide dozer blade and dual wide tires.
