DOOSAN DX225LC-9C
Specifications & Parameters
| Engine Model | DEVELON DL06 |
| Rated Power(kW) | 115 |
| Engine Revolutions(rpm) | 1900 |
| Maximum Torque(N·m) | 680 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 8.3-10.4 |
| Engine Displacement(L) | 5.89 |
| Emisson | Stage V |
| Track width(mm) | 600 |
| Fuel Tank(L) | 400 |
| Hydraulic Tank(L) | 195 |
| Travel Speed(km/h) | 5.7 |
| Bucket Capacity(m³) | 1.05 |
| Bucket Digging Force(kN) | 152 |
| Boom Length(mm) | 5700 |
| Stick Length(mm) | 2900 |
| Maximum Excavation Radius(mm) | 9873 |
| Maximum Digging Height(mm) | 6830 |
| Maximum Digging Depth(mm) | 6592 |
| Specifications(mm) | 9506×2990×2891 |
| Operating Weight(kg&ton) | 21800 |
| Size Class | Medium |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | China |
| Year of Production | 2022 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
Features
Doosan DL06P six‑cylinder electronically controlled diesel engine delivers stable low‑speed torque with simple Tier3 emission setup, no urea system required for low‑cost operation
SPC intelligent load‑sensing hydraulic system dynamically matches pump output to digging load, improving responsiveness while cutting unnecessary fuel consumption
Dual variable displacement main pumps deliver smooth combined flow for fast digging and loading cycles, pre‑installed auxiliary hydraulic piping ready for rock breakers and grapples
Three customizable working modes Power, Standard and ECO allow operators to switch performance for heavy breaking or light earthmoving tasks
Robust LC reinforced long undercarriage with 9 lower track rollers reduces ground pressure and keeps stable performance on muddy construction sites
Thickened boom and arm with reinforced hinge points withstand repeated impact loads during long‑time rock breaking and demolition work
Optional short tail compact radius version enables operation in narrow urban zones and tight roadside construction spaces
Shock‑absorbing enclosed ROPS/FOPS cabin with climate control system reduces operator fatigue during long daily working shifts
7-inch TFT onboard monitor supports real-time machine diagnostics and quick adjustment of hydraulic flow for different attachments
Ground-level grouped service points simplify daily inspection and filter replacement, abundant global spare parts supply lowers long term maintenance cost
Interested in used DOOSAN DX225LC-9C excavator? Click the WhatsApp icon to chat with our sales team for a quicker reply, or leave us a message through the contact form below. If you are looking for a different brand or model, please tell us your purchasing requirements, and we will do our best to help you find the right machine. Send Inquiry
Photos
