Used Doosan DX270HD-9C
Parameters
| Engine Model | DL06 |
| Rated Power(kW) | 141.4 |
| Engine Revolutions(rpm) | 2000 |
| Maximum Torque(N·m) | 720 |
| Inject Type | Direct Injection |
| Fuel consumption(L/h) | 10.2-12.5 |
| Engine Displacement(L) | 5.89 |
| Emisson | Stage III |
| Track width(mm) | 700 |
| Fuel Tank(L) | 412 |
| Hydraulic Tank(L) | 195 |
| Travel Speed(km/h) | 5.8 |
| Bucket Capacity(m³) | 1.5 |
| Bucket Digging Force(kN) | 186 |
| Boom Length(mm) | 5900 |
| Stick Length(mm) | 3000 |
| Maximum Excavation Radius(mm) | 10175 |
| Maximum Digging Height(mm) | 7024 |
| Maximum Digging Depth(mm) | 6810 |
| Specifications(mm) | 10335×3200×3090 |
| Operating Weight(kg&ton) | 26000 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | China |
| Year of Production | 2022 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Check the latest price. |
Features
High-Power DOOSAN DL06 Six-Cylinder Turbocharged Common Rail Diesel Engine
Inline six-cylinder 5.89L diesel engine, rated power 141.4kW. Compliant with China Non-Road Mobile Machinery Stage III Emission Standard, adopts EGR technology without urea SCR or DPF, no urea refilling required. Abundant spare parts supply and low daily maintenance expense for long-hour mine operation.
HD Reinforced Heavy-Duty Working Attachment
HD full name: Heavy Duty. Thickened boom & arm with reinforced welds, bushings and wear plates, specially designed for harsh rock breaking and heavy loading cycles.
FEH Full Electronic Controlled High-Flow VBO Load-Sensing Hydraulic System
Dual variable displacement piston main pumps total flow 438L/min, triple energy regeneration circuit cuts fuel consumption by 10%, factory pre-installed large-flow auxiliary hydraulic line for hydraulic breakers up to 35-ton class. Hydraulic tank capacity 195L, full system oil volume 240L.
LC Extra Long Reinforced Mining Undercarriage
LC full name: Long Chassis. 2480mm wide track gauge with 10 lower support rollers and 700mm thick mining track shoes, extended ground contact length reduces ground pressure to avoid sinking on muddy mine & river ground, superior stability for heavy side lifting and rock slope excavation.
Large-Capacity Standard HD Rock Bucket & Convenient Transport
Standard 1.50m³ heavy-duty rock bucket greatly improves quarry loading efficiency, overall dimension 10335×3200×3090mm, fully transportable on standard flatbed trucks.
ROPS & FOPS Certified Comfort Operator Cabin
Full shock-absorbing operator cabin with ROPS (Roll Over Protective Structure) & FOPS (Falling Object Protective Structure), equipped with auto air conditioning, color LCD monitor and standard rear view camera.
