Used DOOSAN DH300LC-7
Parameters
| Engine Model | DE08TIS |
| Rated Power(kW) | 147 |
| Engine Revolutions(rpm) | 1900 |
| Maximum Torque(N·m) | 680 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 11.0～13.5 |
| Engine Displacement(L) | 8.07 |
| Emisson | Euro 3 |
| Track width(mm) | 700 |
| Fuel Tank(L) | 450 |
| Hydraulic Tank(L) | 290 |
| Travel Speed(km/h) | 5 |
| Bucket Capacity(m³) | 1.27 |
| Bucket Digging Force(kN) | 188 |
| Boom Length(mm) | 6245 |
| Stick Length(mm) | 3100 |
| Maximum Excavation Radius(mm) | 10920 |
| Maximum Digging Height(mm) | 7470 |
| Maximum Digging Depth(mm) | 7190 |
| Specifications(mm) | 10620×3200×3365 |
| Operating Weight(kg&ton) | 29600 |
| Size Class | Medium |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | China |
| Year of Production | 2016 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Check the latest price. |
Features
High-Torque DOOSAN DE08TIS Six-Cylinder Turbocharged Engine
Inline six-cylinder turbo diesel engine, displacement 8.07L, rated power 147kW. Early version Euro II without aftertreatment; late version Euro III only with EGR, no urea tank. Spare parts are widely available with low daily maintenance expense.
LC Extra Heavy-Duty Reinforced Undercarriage
2540mm wide track gauge with 700mm thick mining track shoes and extended ground contact length, low ground pressure prevents sinking on muddy mine & river soil, outstanding stability for heavy lifting and slope excavation.
High-Flow Regenerative Dual-Pump Hydraulic System
Dual variable main pumps total flow 492L/min, smooth synchronized compound movements, factory pre-installed large-flow auxiliary hydraulic line for heavy breakers up to 36-ton class. Hydraulic tank capacity 290L, full system oil volume 385L.
Reinforced Rock Working Equipment
Standard 1.27m³ heavy rock bucket with reinforced cutting edge & tooth holder, optional short arm for rock breaking & long arm for deep dredging, ideal for quarry mining, foundation and mass earthmoving.
Standard Transportation Dimension
Overall dimension 10620×3200×3365mm, fully transportable on standard flatbed trucks for cross-site mining & construction operations.
