DEVELON DX1000HDP
Specifications & Parameters
| Engine Model | PERKINS 2806D |
| Rated Power(kW) | 570.5 |
| Engine Revolutions(rpm) | 2100 |
| Maximum Torque(N·m) | 3420 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 24-30 |
| Engine Displacement(L) | 22.8 |
| Emisson | Stage V |
| Track width(mm) | 500 |
| Fuel Tank(L) | 1300 |
| Hydraulic Tank(L) | 480 |
| Travel Speed(km/h) | 5.5 |
| Bucket Capacity(m³) | 6.2 |
| Bucket Digging Force(kN) | 468 |
| Boom Length(mm) | 7600 |
| Stick Length(mm) | 3600 |
| Maximum Excavation Radius(mm) | 13140 |
| Maximum Digging Height(mm) | 9450 |
| Maximum Digging Depth(mm) | 8620 |
| Specifications(mm) | 13650×4620×4980 |
| Operating Weight(kg&ton) | 100500 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | China |
| Year of Production | 2023 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
Features
High‑Power Mining Stage‑V Engine for 100‑ton‑class open‑pit operation, adopts imported PERKINS 2806J inline six‑cylinder twin‑turbo common‑rail engine, displacement 18L, net power 469kW, EU Stage‑V emission standard with DPF+SCR urea after‑treatment system. Delivers tremendous low‑end torque for hard rock stripping and full‑load loading for 120‑150‑ton mining trucks, stable output under continuous heavy‑load mining conditions with long service life.
9‑Roller reinforced extra‑wide heavy‑duty LC mining undercarriage, nine heavy‑load track rollers on each side with extra‑long‑wide ground‑contact length. Ultra‑thick multi‑rib wear‑resistant track shoes withstand severe rock impact. Ultra‑low ground pressure guarantees reliable anti‑sinking performance on soft mine slopes, optimized stability for heavy digging and side‑lifting tasks.
Triple large‑flow VBO intelligent regenerative hydraulic system, three variable‑displacement main pumps deliver total flow up to 1569L/min. Multi‑energy regeneration circuit for boom, stick and swing stabilizes system pressure during round‑the‑clock open‑pit mining. Realizes smooth synchronized heavy compound movements and ultra‑precise fine control. Factory‑pre‑installed bi‑directional extra‑large‑flow auxiliary hydraulic circuit supports ultra‑heavy hydraulic breakers without refitting. Hydraulic tank capacity 540L, full‑system hydraulic‑oil volume 960L.
Giant heavy‑duty reinforced rock working equipment, standard 5.4‑7.2m³ oversized rock bucket drastically improves loading efficiency in large‑scale open‑pit mines. Two front‑end configurations available for deep overburden stripping or short‑arm heavy‑hammer breaking. Perfectly suited for hard‑rock excavation, mass backfilling and high‑volume quarry mass‑production.
Reinforced safe‑comfort mining operator cabin, thickened ROPS/FOPS falling‑object‑protection air‑conditioned cabin with six‑point hydraulic shock absorption and premium wide air‑suspension seat. 12‑inch industrial touch TFT‑color monitor clearly displays after‑treatment status and real‑time fuel consumption. Equipped with 360° panoramic camera system and DEVELON CONNECT mining telematics for full‑digital remote fleet monitoring, operational‑data statistics and maintenance reminders.
Convenient ground‑level daily maintenance layout, all service ports positioned at ground height. Optional automatic centralized lubrication system. Single‑operator daily inspection of engine oil, filters and hydraulic oil without climbing onto machine. Effectively cuts costly open‑pit‑mining downtime and lifts annual mine output.
Interested in used DEVELON DX1000HDP excavator? Click the WhatsApp icon to chat with our sales team for a quicker reply, or leave us a message through the contact form below. If you are looking for a different brand or model, please tell us your purchasing requirements, and we will do our best to help you find the right machine. Send Inquiry
