CAT MD6310 (Rotary Drill Rigs)
Parameters
| Engine Model | Cat® C32B |
| Rated Power(kW) | 895 |
| Engine Revolutions(rpm) | 1800 |
| Maximum Torque(N·m) | 5499 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 40-50 |
| Engine Displacement(L) | 32.1 |
| Emisson | Tier 4 Final / Stage V |
| Fuel Tank(L) | 1500 |
| Hydraulic Tank(L) | 1200 |
| Travel Speed(km/h) | 1.5 |
| Operating Weight(kg&ton) | 130000 |
| Specifications(mm) | 15000×5500×25000 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | America |
| Year of Production | 2020 |
| Condition | Used |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
| Pull-Down Capacity | Up to 39009 kg |
| Hole Diameter | 229-311 mm |
| Bit Load | Up to 42149 kg |
| Working Weight Range - Minimum/Maximum | 75800/97000 kg |
| Max Drilling Depth | 74.6 m |
| Pull-Down Capacity | 39,009–42,149 kg |
| Mast Height | 13.7 m / 17.5 m |
| Main Pump Flow | 400–500 L/min |
| Ground Pressure | 120–150 kPa |
| Track Width | 1.0 m |
Features
WORLD-CLASS OPERATOR STATION
Ergonomic controls to help operators stay alert and avoid fatigue
Multifunction joystick controls and touchscreen monitors are easy to use and intuitive
Excellent visibility, thanks to multiple cameras and full-length windows
Optional heated and ventilated seat for enhanced operator comfort
100% CAT INTEGRATION
Cat to the core, with common parts and components and consistent design characteristics across all Cat drill models
Shared software for autonomous features
Backed by the world-class support of the Cat dealer network
CAT ELECTRONICS: BACKBONE OF THE MACHINE
Common electronic architecture across all Cat machines to ensure technician familiarity
Cat Electronic Technician (Cat ET) enables fast and easy troubleshooting
Serves as common platform for integrating future autonomy solutions
Product Link™ Elite provides real-time performance tracking
MATCHED POWERTRAIN
Variable air volume for reduced fuel consumption and powerful performance
C32B engine matched to largest “standard” compressor in this class for fast cycle times
Powertrain optimized to withstand rigorous drilling applications
High- and low-pressure configurations offer variable volume air control
Optimal feed force, rotary torque and air, helping to reduce fuel consumption
TECHNOLOGY AND AUTOMATION
Integrated Drill Assist functionality, including auto level, auto retract jacks, auto raise and lower mast, and auto drill
Machine health and performance monitoring keep machine running productively
Drill depth meter helps reduce over- and under-drilling
Ready to connect with the Cat MineStar™ suite of technologies, including Terrain for drilling and Command for drilling
SAFETY
Three standard cameras and large windows give the operator excellent visibility
MineStar Command for drilling enables remote or autonomous operation — removing operator from the machine
Seven engine shut-down buttons
Slip-resistant surfaces for safer ingress/egress and service
LED interior lights and backlit joysticks and keypads; exterior spot and flood lights illuminate paths for ingress/egress
SUSTAINABILITY
Designed to use less fuel, which reduces engine emissions
Tier 4 Final engines reduce NOx and particulate matter
Reduced waste and lower owning and operating costs thanks to increased commonality of systems and components, plus a reduction in unique part numbers
Longer maintenance intervals that decrease the amount of waste contributed to the environment
