Used VOLVO EC240E
Parameters
| Engine Model | Volvo D7E EBE2 |
| Rated Power(kW) | 130 |
| Engine Revolutions(rpm) | 2000 |
| Maximum Torque(N·m) | 870 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 13-15 |
| Engine Displacement(L) | 7.7 |
| Emisson | China Stage Ⅳ |
| Track width(mm) | 600 |
| Fuel Tank(L) | 380 |
| Hydraulic Tank(L) | 190 |
| Travel Speed(km/h) | 5.5 |
| Bucket Capacity(m³) | 1.98 |
| Bucket Digging Force(kN) | 160.8 |
| Boom Length(mm) | 6000 |
| Stick Length(mm) | 2970 |
| Maximum Excavation Radius(mm) | 10260 |
| Maximum Digging Height(mm) | 9690 |
| Maximum Digging Depth(mm) | 6980 |
| Specifications(mm) | 10020×2990×3040 |
| Operating Weight(kg&ton) | 24300 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | Korea |
| Year of Production | 2023 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Check the latest price. |
Features
1、 Power system: High efficiency and low consumption, National IV emissions
Equipped with Volvo D7E/EBE2 engine, rated power of 130kW/2000rpm, low-speed high torque, sufficient power reserve.
Adopting common rail direct injection, turbocharging, and automatic idle technology, it has excellent fuel economy, meets the National IV emission standards, and has lower noise and emissions.
Equipped with a 50L urea tank and mature exhaust gas post-treatment, it is suitable for construction sites with strict environmental requirements.
2、 Hydraulic system: intelligent and precise, efficient and energy-saving
Fully electronically controlled load sensitive hydraulic system, dual variable axial piston pump, flow distribution according to demand, hydraulic efficiency increased by about 6%, fast action response, and high control accuracy.
Integrated Automatic Sensing Working Mode (ACS), supporting 5 modes: I (idle), F (fine), G (economy), H (heavy load), and P (fast), with one click matching of working conditions, balancing efficiency and fuel consumption.
Standard arm floating function, making flat work easier and reducing cycle time.
The digging force of the bucket is 181kN, the digging force of the boom is 128kN, the turning torque is large, and the performance of heavy load and crushing operations is strong.
3、 Cab: Comfortable and safe, with friendly handling
Integrated ROPS anti roll cab, with three-stage shock absorption of silicone oil, spring, and rubber, with low vibration and noise (about 72dB inside the cab).
Suspended ergonomic seats, 8-way adjustment+seat heating, adjustable armrests at multiple angles, making long-term work less tiring.
360 ° panoramic view, front windshield can slide up for storage, and the lower glass can be removed; Standard rearview and right side view camera, with few blind spots.
8-inch color intelligent monitor, touch screen operation, real-time display of working conditions, fuel consumption, and fault codes, supporting Chinese.
Sealed and pressurized+14 outlet air conditioner, dust-proof and insulated; Standard Bluetooth radio and cleaning air gun, comfortable and convenient.
4、 Structure and durability: reinforced design to adapt to heavy loads
The working weight is 23.5-24.3t, with standard 1.2-1.3m ³ bucket and optional 1.05-1.98m ³ bucket, suitable for multiple working conditions.
Thickened and reinforced key parts of the upper and lower frames, boom/arm, and walking frame+robot welding, wear-resistant and durable for mining/heavy-duty construction sites.
Extended track chassis, large grounding area, good stability, climbing ability of 35 °, strong passability on muddy/rough ground.
Key hinge points are reinforced with bushings and seals to reduce wear and extend service life.
5、 Maintenance and intelligent management: convenient and worry free, reducing downtime
Ground centralized maintenance: lubrication points, filter elements, fuel/oil filling ports are centralized, anti slip platform+side ladder, and a single person can quickly complete daily inspections.
Long term filter element+large capacity oil tank: The hydraulic oil/oil replacement cycle is long, reducing maintenance frequency.
CareTrack intelligent monitoring system: remote real-time tracking of location, fuel consumption, working conditions, and fault warnings, supporting GSM/satellite transmission for easy fleet management.
Electrical system IP55 protection, waterproof and dustproof, suitable for harsh construction sites; 2 × 12V/200Ah large capacity battery, reliable starting.
