VOLVO EC360
Specifications & Parameters
| Engine Model | Volvo D12D |
| Rated Power(kW) | 198 |
| Engine Revolutions(rpm) | 1700 |
| Maximum Torque(N·m) | 1,335 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 14-16 |
| Engine Displacement(L) | 7.7 |
| Emisson | China Stage Ⅳ |
| Track width(mm) | 600 |
| Fuel Tank(L) | 620 |
| Hydraulic Tank(L) | 220 |
| Travel Speed(km/h) | 5.5 |
| Bucket Capacity(m³) | 1.35 |
| Bucket Digging Force(kN) | 218 |
| Boom Length(mm) | 6450 |
| Stick Length(mm) | 2850 |
| Maximum Excavation Radius(mm) | 11115 |
| Maximum Digging Height(mm) | 7245 |
| Maximum Digging Depth(mm) | 7485 |
| Specifications(mm) | 11100×3190×3380 |
| Operating Weight(kg&ton) | 36,900 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | Korea |
| Year of Production | 2023 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
Features
High homework efficiency and productivity improvement
The bucket has a capacity of 1.35-3.0 m ³, suitable for various work scenarios such as trenching, loading, crushing, etc
The bucket size of the new generation "National IV" models (such as EC360 CN4) has increased by about 25% compared to the previous generation, significantly improving productivity
Strong power and fuel economy
Equipped with Volvo D12D or D8M engines, with a rated power of 198-220 kW, it meets the National IV/Euro V emission standards, is environmentally compliant, and has high reliability
Adopting an electronic hydraulic system, the flow rate is adjusted as needed to reduce internal losses and improve fuel efficiency by about 10%
Some users have provided feedback that the actual fuel consumption is about 24-27 liters per hour
Excellent handling and comfort
Equipped with L8 controller, supporting customization of shortcut buttons (such as hydraulic priority, mode switching)
Comfort Drive Control can be operated through a handle roller, replacing traditional pedals and reducing operator fatigue
The cab meets ROPS/FOPS standards, with low noise and a wide field of view. It can be equipped with a panoramic/360 ° camera system and Co Pilot assisted excavation system to achieve precise excavation and obstacle avoidance
Durable structure and easy maintenance
The whole machine is made of high-strength steel, the chassis supports self balancing function, and is compatible with intelligent modules such as iron armor cloud box
Centralized layout of maintenance points, accessible from the ground, reducing the number of hoses and couplings, lowering failure rates and maintenance time
Support remote monitoring of device status, fuel consumption, alarms, and maintenance reminders on the Wo+Smart Cloud platform
Multi functional expansion capability
Quick replacement of Volvo original factory accessories such as buckets, breakers, hydraulic shears, etc., suitable for various engineering needs
