Used SANY SCA4000A (Crawler Crane)
Parameters
| Engine Model | Cummins X12-C400 |
| Rated Power(kW) | 298 |
| Engine Revolutions(rpm) | 2100 |
| Maximum Torque(N·m) | 1898 |
| Inject Type | Direct Injection |
| Fuel consumption(L/h) | 18~25 |
| Engine Displacement(L) | 11.8 |
| Emisson | EU Stage V |
| Fuel Tank(L) | 800 |
| Hydraulic Tank(L) | 520 |
| Travel Speed(km/h) | 1.0 |
| Operating Weight(kg&ton) | 67000 |
| Specifications(mm) | 14300×3000×3300 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | China |
| Year of Production | 2020 |
| Condition | Used |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Check the latest price. |
| Boom Configuration (with Superlift) | 36~84m |
| Mixed Boom Configuration | 45~99m |
| Luffing Jib Length (with Superlift) | 21~81m |
| Fixed Jib Length | 9m |
| Maximum Luffing Jib Configuration (with Superlift) | 84+81m |
| Maximum Wind Power Configuration | 90+9m |
| Max Boom + Max Fixed Jib | 36+9m |
| Longest Boom + Longest Jib | 84+81m |
| Gradeability | 15% |
| Max. Lifting Capacity | 400T |
| Maximum Lifting Moment | 2695t·m |
Features
Driver Comfort
New cab design:
more beautiful, comfortable and safe.
High Performance
Strong lifting capacity, low ground pressure, small steering radius, great grade ability, no need for outriggers during the operation, and can travel with the load.
Efficient Disassembly and Transportation Performance
The whole machine adopts modular design, and each transportation unit is designed independently.
Safety Insurance
Real-time monitoring of the center of gravity of the whole machine to provide safety insurance for hoisting operations and traveling with boom.
Interested in this excavator? Leave us a message through the contact form on our website or click the WhatsApp button for a faster response from our sales team. If you are looking for a different brand or model, please tell us your purchasing requirements, and we will do our best to help you find the right machine. Send Inquiry
Photos
