CAT EC40N
Parameters
| Engine Model | AC Electric Motor 36/48V |
| Rated Power(kW) | / |
| Engine Revolutions(rpm) | / |
| Maximum Torque(N·m) | / |
| Inject Type | / |
| Fuel consumption(L/h) | / |
| Engine Displacement(L) | / |
| Emisson | / |
| Fuel Tank(L) | / |
| Hydraulic Tank(L) | / |
| Travel Speed(km/h) | 14.5 |
| Operating Weight(kg&ton) | 5615 |
| Specifications(mm) | 2545×1100×2220 |
| Size Class | Medium |
| Power Type | Electric |
| Walking Mode | Wheel |
| Country of Origin | China |
| Year of Production | 2024 |
| Condition | Used |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
| Rated Capacity | 3500kg |
| Load Center | 600mm |
| Turning Radius | 2245mm |
| System Voltage | 36V/48V |
| Battery Weight | 1600 kg |
| Loaded Lift Speed | 0.22 m/s |
| Lowering Speed | 0.5 m/s |
| Battery Capacity | 1400 Ah |
Features
Productivity
Exceptional Run Times – Work longer with up to two shifts on one battery charge without sacrificing performance, thanks to Cat Lift Trucks 3-phase AC technology and regenerative braking.
Advanced drive system – no brushes or commutator
All AC hydraulic system
Enhanced electric power steering
Adaptable Performance Modes – Optimize your performance and efficiency by simply selecting one of the pre-set operating modes. Profits are maximized by achieving the right balance between output and economy.
Awareness
Operator Presence Detection System – This integrated, computer-based feedback system uses both audible and visual indicators to alert the operator to potentially hazardous situations, while increasing operator awareness.
Highly-Visible Orange Seat Belt – Helps to clearly see when the operators are wearing their seat belt.
Energy Efficiency
Regenerative Braking – Activated when the lift truck decelerates, changes directions, or service brakes are applied, this feature helps to return energy to the battery. The result is extended run times and extended service brake life.
Improves battery life
Reduces brake wear
Minimizes heat build up
Two-Stage Hydraulic System – Allows these cushion tire lift trucks to provide precise load handling, fast lift speeds and less energy consumption.
Ergonomics
Adjustable Full-Suspension Seat – The full-suspension, standard vinyl seat can be adjusted to give the operator the most comfortable position possible:
Front and back
Lumbar support
Suspension
Narrow Steering Column
Easy to operate
Tilt-adjustable
Full-hydrostatic steering
