XCMG XT1056U（Telehandler）
Parameters
| Engine Model | Cummins QSF3.8 |
| Rated Power(kW) | 97 |
| Engine Revolutions(rpm) | 2200 |
| Maximum Torque(N·m) | 488 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 14~16 |
| Engine Displacement(L) | 3.8 |
| Emisson | Tier4 Final |
| Fuel Tank(L) | 220 |
| Hydraulic Tank(L) | 195 |
| Travel Speed(km/h) | 32 |
| Operating Weight(kg&ton) | 13200 |
| Specifications(mm) | 6980×2550×3120 |
| Size Class | Medium |
| Power Type | Diesel |
| Walking Mode | Wheel |
| Country of Origin | China |
| Year of Production | 2023 |
| Condition | Used |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
| Max.lifting capacity（lb） | 10000 |
| Max.lifting height（ft） | 56 |
| Lift capacity at maximum height（lb） | 5000 |
| Max.outreach（ft） | 43 |
| Lift capacity at maximum reach（lb） | 3000 |
| Max.traveling speed（mph） | ≥20 |
| Max.traction force（kN） | ≥65 |
| Min.turning radius（ft） | ≤14.11 |
| Rated power（hp/r/min） | 130/2000 |
Features
Excellent Lifting Capacity
Max 10000lb load, 56ft lift height, 5000lb capacity at full height; extendable outriggers guarantee stable high-position work.
EPA T4F Certified Power
Cummins QSF3.8 engine, Tier4 Final compliant, low fuel consumption, no DPF maintenance for North America market.
All-Terrain Driving
4WD + 3 steering modes (2WS/4WS/Crab steer), heavy-duty off-road tires for muddy & rough job sites.
Flexible Multifunction
Single joystick load-sensing hydraulic system, quick change attachments: fork, bucket, lifting hook.
Comfort & Safety
Panoramic AC cabin, robust reinforced chassis for stable anti-tipping performance.
