CAT PL87 (Pipelayers)

used CAT PL87 (Pipelayers)
Used CAT PL87 (Pipelayers) For Sale
Request a Quote

Parameters

Specifications & Parameters
Engine ModelCAT C15
Rated Power(kW)238
Engine Revolutions(rpm)2100
Maximum Torque(N·m)1560
Inject TypeDirect Injection
Fuel consumption(L/h)19-26
Engine Displacement(L)15.2
Emisson Tier4F available
Fuel Tank(L)650
Hydraulic Tank(L)370
Travel Speed(km/h)7
Operating Weight(kg&ton)52600
Specifications(mm)9020×3610×4950
Size ClassMedium
Power TypeDiesel
Walking ModeCrawler
Country of OriginAmerica
Year of Production2022
ConditionUsed
Working Hours(h)2000/5000/7000
Price($)Get the Latest Price from sales via WhatsApp
Rated Lift Capacity 216000lb
Standard Boom Length 9.6m, extended boom optional
Flywheel Power 319HP (238kW) @2100rpm
Max Gradeability 35°
Travel Type Tracked full hydraulic drive



Features

CAT C15 reliable engine, stable power output for heavy pipeline hoisting work.
Max lifting capacity up to 97.98 ton, ideal for large diameter pipeline laying project.
Heavy-duty tracked undercarriage, excellent off-road performance on muddy & uneven construction ground.
Mature full hydraulic system, smooth lifting operation and low maintenance cost.
