XCMG XT1256U（Telehandler）
Parameters
| Engine Model | Cummins QSF3.8 Engine |
| Rated Power(kW) | 97 |
| Engine Revolutions(rpm) | 2200 |
| Maximum Torque(N·m) | 488 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 15～17 |
| Engine Displacement(L) | 3.8 |
| Emisson | Tier4 Final |
| Fuel Tank(L) | 220 |
| Hydraulic Tank(L) | 195 |
| Travel Speed(km/h) | 28 |
| Operating Weight(kg&ton) | 13800 |
| Specifications(mm) | 6980×2550×3120 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Wheel |
| Country of Origin | China |
| Year of Production | 2023 |
| Condition | Used |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
| Max.lifting capacity | 12000lb |
| Max.lifting height | 56ft |
| Lift capacity at maximum height | 5000lb |
| Max.outreach | 43ft |
| Lift capacity at maximum reach | 3500lb |
| Max.traveling speed | ≥20mph |
| Max.traction force | ≥65kN |
| Min.turning radius | ≤14.11ft |
| Rated power | 130/2000hp/r/min |
Features
Strong Lifting
12000lb max load, 56ft lift height, 5000lb capacity at full height; extendable outriggers for stable high lifting.
EPA T4F Power
Cummins QSF3.8 engine, Tier4 Final compliant, low fuel consumption, no DPF maintenance.
All-terrain Mobility
4WD & 3 steering modes (2WS/4WS/Crab steer), big rugged tires for rough ground.
Multi-purpose Work
Load-sensing hydraulics + single joystick control; quick-fit attachments for fork/bucket/hook.
Comfort & Durability
AC panoramic cabin; heavy reinforced chassis with 13.8t weight for anti-tip safety.
