Used KOBELCO SK135SR-7
Parameters
| Engine Model | 4JJ1XDJA |
| Rated Power(kW) | 73 |
| Engine Revolutions(rpm) | 2000 |
| Maximum Torque(N·m) | 365 |
| Inject Type | Electronic Injection |
| Fuel consumption(L/h) | 5.2-5.9 |
| Engine Displacement(L) | 2.999 |
| Emisson | Stage V |
| Track width(mm) | 500 |
| Fuel Tank(L) | 186 |
| Hydraulic Tank(L) | 89.9 |
| Travel Speed(km/h) | 5.6 |
| Bucket Capacity(m³) | 0.5 |
| Bucket Digging Force(kN) | 92.9 |
| Boom Length(mm) | 3700 |
| Stick Length(mm) | 2380 |
| Maximum Excavation Radius(mm) | 8190 |
| Maximum Digging Height(mm) | 9190 |
| Maximum Digging Depth(mm) | 5520 |
| Specifications(mm) | 7430×2490×2810 |
| Operating Weight(kg&ton) | 13800 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | Japan |
| Year of Production | 2020 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Check the latest price. |
Features
Short tail swing compact size 7430×2490×2810mm, ultra-small rear swing radius
500mm heavy steel tracks, optional wide shoes for soft muddy ground
Two arm options (standard/long) for deeper digging & extended reach
Isuzu turbo 4-cylinder engine, max torque 365N·m, fuel use 4.5–6.7 L/h
89.9L hydraulic tank, pre-installed breaker piping for demolition work
270° panoramic camera, low noise cab, Tier3/Stage V dual emission options
Interested in this excavator? Leave us a message through the contact form on our website or click the WhatsApp button for a faster response from our sales team. If you are looking for a different brand or model, please tell us your purchasing requirements, and we will do our best to help you find the right machine. Send Inquiry
Photos
