KOBELCO SK850LC-10
Specifications & Parameters
| Engine Model | HINO E13C-VM |
| Rated Power(kW) | 370 |
| Engine Revolutions(rpm) | 1800 |
| Maximum Torque(N·m) | 2260 |
| Inject Type | Direct Injection |
| Fuel consumption(L/h) | 24-30 |
| Engine Displacement(L) | 12.91 |
| Emisson | Tier 4 |
| Track width(mm) | 900 |
| Fuel Tank(L) | 1100 |
| Hydraulic Tank(L) | 320 |
| Travel Speed(km/h) | 3.8 |
| Bucket Capacity(m³) | 4.8 |
| Bucket Digging Force(kN) | 415 |
| Boom Length(mm) | 7300 |
| Stick Length(mm) | 3200 |
| Maximum Excavation Radius(mm) | 12330 |
| Maximum Digging Height(mm) | 8760 |
| Maximum Digging Depth(mm) | 7960 |
| Specifications(mm) | 14020×4200×4460 |
| Operating Weight(kg&ton) | 83000 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | Japan |
| Year of Production | 2023 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
Features
The 83‑ton KOBELCO SK850LC‑10 heavy‑duty crawler excavator is purpose‑built for quarry, open‑pit mining and large‑volume earth‑moving projects. It delivers high production output, outstanding digging power and long‑term durability for continuous heavy‑cycle mining‑site operations.
HINO E13CBB 6‑cylinder turbo‑intercooled diesel engine delivers 370 kW rated power and massive 2120 N·m low‑speed torque. Hydraulically driven twin‑fan cooling system adapts fan speed according to temperature, reduces fuel consumption and noise. H/S/ECO three working‑mode selection matches full‑power mining, standard earthwork and fuel‑saving operation for different site demands.
High‑flow optimized main‑pump hydraulic system minimizes internal pressure loss, generates powerful bucket breakout force and arm crowding force for rock digging and stockpile loading. Factory‑fitted bi‑directional auxiliary hydraulic lines plus quick‑hitch piping support heavy mining attachments. Hydraulic‑filter clogging sensor sends real‑time alarm to avoid component wear caused by oil contamination.
Extra‑thick heavy‑duty boom & arm with reinforced high‑stress sections resists rock impact and abrasion. Long‑contact LC‑type undercarriage fitted with triple track‑guide protectors on each side frame improves track‑chain service life. Class‑leading drawbar pull enables stable climbing and travelling over rough mining terrain.
Spacious ROPS‑FOPS certified operator cabin equipped with large‑size color multi‑display monitor, preset attachment flow‑control function, automatic air‑conditioning and ergonomic low‑effort pilot joysticks. Multi‑view monitoring cameras offer all‑round visibility to enhance site‑operation safety.
Convenient side‑access service walkway and grouped ground‑level maintenance points simplify daily inspection, grease refilling and filter replacement. Long‑life hydraulic filter reaches 1000‑hour replacement interval; long‑life hydraulic oil supports up to 5000‑hour service cycle to cut downtime and operating cost. Global spare‑parts network maintains stable residual value for mining‑fleet investment.
Multiple optional attachments: heavy‑duty rock bucket, mining ripper, hydraulic quick coupler, heavy rock breaker and reinforced mining track shoes for diversified heavy‑duty conversion.
Interested in used KOBELCO SK850LC-10 excavator? Click the WhatsApp icon to chat with our sales team for a quicker reply, or leave us a message through the contact form below. If you are looking for a different brand or model, please tell us your purchasing requirements, and we will do our best to help you find the right machine. Send Inquiry
