KOBELCO SK350D
Specifications & Parameters
| Engine Model | HINO J08E-TM |
| Rated Power(kW) | 209 |
| Engine Revolutions(rpm) | 2000 |
| Maximum Torque(N·m) | 1080 |
| Inject Type | Direct Injection |
| Fuel consumption(L/h) | 15-17 |
| Engine Displacement(L) | 7.68 |
| Emisson | China Stage III |
| Track width(mm) | 600 |
| Fuel Tank(L) | 580 |
| Hydraulic Tank(L) | 250 |
| Travel Speed(km/h) | 5.5 |
| Bucket Capacity(m³) | 1.6 |
| Bucket Digging Force(kN) | 206 |
| Boom Length(mm) | 6,500 |
| Stick Length(mm) | 3300 |
| Maximum Excavation Radius(mm) | 11060 |
| Maximum Digging Height(mm) | 10820 |
| Maximum Digging Depth(mm) | 7560 |
| Specifications(mm) | 11200×3400×3420 |
| Operating Weight(kg&ton) | 33000 |
| Size Class | Large |
| Power Type | Diesel |
| Walking Mode | Crawler |
| Country of Origin | China |
| Year of Production | 2018 |
| Condition | Used |
| Inventory Quantity | 3 |
| Working Hours(h) | 2000/5000/7000 |
| Price($) | Get the Latest Price from sales via WhatsApp |
Features
Powerful power system
Equipped with Hino J08ETM-KSDL engine, rated power of 209 kW, rated speed of 2100 r/min, maximum torque of 998 N · m, using direct injection, water cooling, four stroke, turbocharging and built-in intercooler technology to ensure high power output and fuel efficiency
Efficient homework ability
The bucket capacity is 1.6 m ³, suitable for large-scale excavation and loading operations
The rotation speed reaches 10.0 rpm, improving the efficiency of the work cycle
The maximum excavation depth is 7560 mm, the maximum excavation height is 10580 mm, and the unloading height is 7370 mm, with a wide range of operations
Excellent fuel saving performance
Compared to the previous generation model, it can significantly reduce fuel consumption and lower operating costs under the same workload
High reliability and durability
Made of high-strength steel, suitable for Harsh construction environment
The hydraulic system adopts a dual variable displacement axial piston pump, with a maximum flow rate of 2 × 294 L/min for the main pump and a working pressure of 34.3 MPa, ensuring stable and efficient operation
The walking system is equipped with two sets of two speed variable piston motors to adapt to different terrain requirements
Good passability and stability
The grounding pressure is 66 kPa (some data shows 50.5 kPa, depending on the track configuration)
Climbing ability up to 70% (approximately 35 °), equipped with wide track (600 mm or 800 mm optional), enhancing stability during operations on soft or sloping terrain
Humanized design
The driver's cabin has a wide field of view, comfortable handling, and conforms to ergonomics
Provide compatibility with multiple attachments (such as grab buckets, breakers, etc.) to improve equipment utilization
Interested in used KOBELCO SK350D excavator? Click the WhatsApp icon to chat with our sales team for a quicker reply, or leave us a message through the contact form below. If you are looking for a different brand or model, please tell us your purchasing requirements, and we will do our best to help you find the right machine. Send Inquiry
Photos
